世聯翻譯公司完成軟件說明相關內容英文翻譯
Name: Karlheinz SchmidtDocument: p:\konstruktion\dokus\benutzerinfo\ab 2010\mk\wmk 520,530,550\en_zusatzinfo messerkopf.docSupplement to information for use- VCM 550; VCM 530; CM 520- WMK 2M Cutter Head- Power Tool:Cutter shaft and WMK cutter head marking.Marking1. The hexagonal position of the cutter shaft is defined and marked by a red dot as shown in the picture. Borehole for centering pin2. The balancing disk of the WMK-2M cutter head with a borehole for the centering pin of the cutter set no. 1 is pushed on the cutter shaft as shown in the picture. (cutter shaft marking at top; borehole for centering pin at top)05/07/08Page 2/3Date: 11.10.11 10:58:00Name: Karlheinz SchmidtDocument: p:\konstruktion\dokus\benutzerinfo\ab 2010\mk\wmk 520,530,550\en_zusatzinfo messerkopf.doc3 Slide cutter set 1 on the cutter shaft. The centering pin will align with thebalancing disk.This type of fixation ensures that cutter 1 is always aligned in thedirection of the red dot on the cutter shaft.4. Fit all cutter sets and intermediate disks. Then mount the end disk withthe marking on the cutter shaft. (observe the cutter shaft and end diskmarking)05/07/08Page 3/3Date: 11.10.11 10:58:00Name: Karlheinz SchmidtDocument: p:\konstruktion\dokus\benutzerinfo\ab 2010\mk\wmk 520,530,550\en_zusatzinfo messerkopf.docSafety screw Power tool5. Fit cap nut onto cutter shaft.Use power tool to tighten cutter head.Important: Cutter 1 must always point upwards whentightening.Secure cap nut with safety screw.Why are parts marked?A 550 ltr. cutter consists of relatively heavy cutter head components.It must be easy to slide the components onto the hexagonal fitting of the cutter shaft andtighten them securely. It involves working with the defined play of the hexagonal fitting ofthe cutter shaft and its components.The play has been taken into account for the balancing disk for cutter no. 1.Unitrans世聯翻譯公司在您身邊,離您近的翻譯公司,心貼心的專業服務,專業的全球語言翻譯與信息解決方案供應商,專業翻譯機構品牌。無論在本地,國內還是海外,我們的專業、星級體貼服務，為您的事業加速！世聯翻譯公司在北京、上海、深圳等國際交往城市設有翻譯基地，業務覆蓋全國城市。每天有近百萬字節的信息和貿易通過世聯走向全球！積累了大量政商用戶數據，翻譯人才庫數據，多語種語料庫大數據。世聯品牌和服務品質已得到政務防務和國際組織、跨國公司和大中型企業等近萬用戶的認可。 專業翻譯公司,北京翻譯公司,上海翻譯公司,英文翻譯,日文翻譯,韓語翻譯,翻譯公司排行榜,翻譯公司收費價格表,翻譯公司收費標準,翻譯公司北京,翻譯公司上海。- 上一篇：世聯翻譯公司完成網站模塊內容中文翻譯
