智能壓力變速器Intelligent pressure transmission
安裝使用說明書Installation instructions
北京瑞普恩德斯豪斯儀表有限公司Beijing Endress+Hauser Ripenss Instrumentation Co.,Ltd
第二頁
智能壓力變速器安裝使用說明書Intelligent pressure transmission installation instructions
智能壓力變速器是德國E+H公司新近推向市場的智能型儀器
Intelligent pressure transmission is Germany E + H company newly brought to the market of intelligent instruments
PMC和PMP的區別在于PMC采用陶瓷傳感器，而PMP采用擴散硅傳感器
PMC and PMP differ in that PMC uses ceramic sensors and PMP uses diffusion silicon sensors
目錄catalogue
技術數據technical data
負載特性load characteristic
普通型電氣連接Normal electrical connections
本安型接線框圖Intrinsically safe wiring diagram
隔爆型接線和安裝應注意explosion proof type connection and installation should pay attention to
本安型安裝使用時應注意Intrinsically safe type installation and using should pay attention to
安裝方式installation method
安裝后通過以下方法調整顯示表的方向using the following method to adjust the direction of the display after installation

零點滿度調節Zero and full adjustment
標定模式下的顯示Calibration Mode display
按鍵設定零點Button to set zero point
按鍵設定滿度Button to set full point
偏壓bias voltage
標定Calibration
無顯示標定No display calibration
帶顯示標定Display calibration
阻尼設定damping setting
貯存storage
運輸transportation
使用期限service life
產品配套Product Support
第三頁：
技術數據technical data
輸出output
按用戶需要疊加數據信號stack data signal according to user needs

協議agreement
溫度影響temperature effect
零點或滿度輸出zero or full output
線性度linearity
含遷移后量程range including after change
量程比range ratio
遲滯lag
重復性repeatability
預熱時間preheating time
響應時間response time
長期漂移long term drift
輸出阻尼output damping
允許溫度allowable temperature
環境溫度environment temperature
普通型ordinary type
本安型Intrinsically safe type
隔爆型flame-proof type
介質溫度medium temperature
防爆型explosion proof type
工作電壓working voltage
振動影響vibration influence
下述情況無影響Had no effect on the following situation
第四頁
振程vibration level
防護等級level of protection
防爆標志explosion-proof sign
本安型Intrinsically safe type
隔爆型flame-proof type
本安型應與以下四種安全柵中的任一種組成本安防爆系統
Intrinsically safe type should combine with either of the following four kinds of safety barrier to be safety explosion protection system
現場顯示status display
LCD數字LCD Digital
棒圖顯示或指針式模擬顯示（任選件）Bar graph display or pointer analog display(any one)

防爆型explosion proof type
普通型ordinary type

第五頁
普通型電氣連接Normal electrical connections
檢測detection
本安型接線框圖Intrinsically safe wiring diagram

安全柵Safety Barrier
危險區danger area
安全區safety area
本安型Intrinsically safe type
第六頁
防爆型接線和安裝應注意Explosion-proof wiring and installation should pay attention to
開蓋前務必切斷電源Be sure to cut off power supply before open
接線后或顯示表調整方向后，應注意將蓋旋緊再用蓋側的金屬塊通過螺釘壓緊在蓋的邊沿上
After wiring or adjusting display direction, pay attention to tighten it and use metal block by screw clamps on the edge of the cove.
隔爆型電源電壓Flameproof power supply voltage
隔爆型選用的電纜線外徑，必須與密封圈內徑相配Flameproof type’s cable diameter must be matched with the sealing ring inside diameter

變送器外殼設有接地端子，用戶在安裝使用時應可靠接地
Transmitter shell is equipped with grounding terminals. Should be reliable grounding when used in the installation
用戶在安裝使用和維護產品時應同時遵守GB50058-92和GB3836.15-2000的有關要求
Users shall comply with GB3836.15-2000 and GB50058-920 on request in the installation and maintenance of the products

電纜引入口應配用經防爆認可的Exd C等級的電纜引入裝置
Cable introduce mouth should be equipped with Exd C level of the explosion-proof cable entry device

本安型安裝使用時注意Intrinsically safe type should pay attention to when installation and using
變送器必須與安全柵配套使用構成本安防爆系統
Transmitter must be used with safety gate to compose intrinsically safe type explosion protection system

夲安系統的接線請同時參閱產品說明書和安全柵使用說明書
intrinsically safe type system wiring should refer to product specifications and safety barrier operation instruction at the same time
本安系統的布線應盡量避免外界電磁干擾的影響，并將電纜分布參數控制在0.06uf和1mH以內
Intrinsically safe type wiring should avoid the influence of outside electromagnetic interference as far as possible, and cable distribution parameters should be controlled within 0.06 uf and 1 mh
安全柵的安裝、使用和維護應遵守安全柵使用說明書
Safety barrier installation operation and maintenance shall comply with the safety barrier operating instructions
用戶在安裝使用和維護產品時務必認真閱讀產品安裝使用說明書，并嚴格遵守和的有關要求要求
Please read the product installation instructions, and strictly comply with relevant requirements ofandin the installation operation and maintenance of this product
變送器外殼設有接地端子，用戶在安裝使用時應可靠接地
Transmitter shell is equipped with grounding terminals, should be reliable grounding when use in the installation

第七頁
安裝方式installation mode
直裝式：通過螺紋或法蘭連接件直接安裝于工藝設備，測量精度和安裝方向無關
direct-mounted  type:  installed directly on the process equipment  through the threaded or flanged fittings,  measurement precision has nothing to do with  installation direction

管架式：采用導管引壓，用安裝支架裝于水平管架或垂直管架上（如圖）
Pipe rack type: using catheter to bring pressure, installed in horizontal or vertical piping support with mounting bracket (as shown in the picture)

墻裝：采用導管引壓，用安裝支架固定于墻面（如圖）
Wall type: using the pipe to bring pressure, installed to the wall with mounting bracket. (as shown in the picture)

水平管架horizontal pipe rack
垂直管架vertical pipe rack

墻裝 wall type
第八頁
安裝后可以通過以下方法調整顯示表的方向
After installation, can use the following method to adjust the direction of the display

松開殼體上的螺釘，殼體可轉動270度（注意調整后仍將螺釘旋緊）
Loosen the screw on the shell, rotating shell 270 degrees (note adjusted screw tightening)
打開顯示窗蓋，顯示表可90度一級轉動到所需位置
Open the display window cover, display table can be turned 90 degrees to the required position
向外推開卡頭push the card head out
第九頁
零點滿度調節zero and full adjustment
壓力與電流顯示Pressure and current display
兩個例子two examples
標定的測量量程Calibrated measuring range
相對壓力relative pressure
絕對壓力absolute pressure
第十頁
標定模式下的顯示display of the calibration mode
顯示壓力零點Display the zero pressure
顯示壓力滿度Display the full pressure
傳感器例sensor example
零點zero point
滿度f(wàn)ull point
量程range
顯示display
傳感器低限Sensor low limit
傳感器高限Sensor high limit
在標定零點和滿度期間，條形顯示器示出的壓力量程和傳感器測量范圍極限
Between the calibrated zero and full point, bar display shows the pressure range and sensor measurement range limit

反向電流輸出Reverse current output
第十一頁
按鍵設定零點Button to set zero point
零點顯示zero point display
按+Z或-Z press  or
松開兩秒后顯示返回正常Loosen for two seconds,  display returns to normal
按鍵button
增加零點壓力Increase the zero point pressure
按+Z兩次之后保持至所需值A(chǔ)fter press the + Z button twice, keep to the required value
減少零點壓力decrease the zero point pressure
按-Z兩次之后保持至所需值A(chǔ)fter press the - Z button twice, keep to the required value
第十二頁
按鍵設定滿度Button to set full point
滿度顯示full point display
按+S或-S press or
松開兩秒后顯示恢復正常after Loosen for  two seconds,  the display returns to normal
按鍵press button
增加滿度壓力increase full point pressure
按+S兩次后保持至所需值A(chǔ)fter press the + S button twice, keep to the required value

減少滿度壓力decrease the full point pressure

按-S兩次之后保持至所需值A(chǔ)fter press the- Z button twice, keep to the required value

第十三頁
偏壓bias voltage
靜壓柱及方向效應的校正Hydrostatic column and direction effect correction
顯示偏壓exhibit bias voltage

同時按+Z及+S或同時按-Z及-S，兩秒后顯示恢復正常
press + S and + Z At the same time or press- Z and the –s at the same time, two seconds later returned to normal

偏壓登陸bias voltage landing
按+Z及+S兩次press +z and +S twice
清除偏壓clear bias voltage
按-Z及-S兩次press  and  twice
第十四頁
標定Calibration
一般說明general description
量程零點和滿度可以在傳感器測量極限內任意設定，注意滿度不能小于額定量程的5%
zero and full range can be set arbitrarily in sensor measurement, note full range cannot be less than the 5% of rated range
無顯示的變送器標定No display transmitter calibration
使用壓力標定器施加準確的標準壓力Using pressure calibrator accurately sets standard pressure
如果所加標準壓力不能和量程零點和滿度恰好相等If the standard pressure is not exactly equal to zero and full point range
請按下式計算相關電流press calculate the related current according to the following formula
電流current
接近量程零點的滿度或滿度的標準壓力Close to zero of the full range or full range standard pressure
零點壓力zero point pressure
滿度壓力full point pressure
第十五頁
無顯示標定No display calibration
兩種可能 Two Possibilities
標準壓力恰與量程零點和滿度相等Standard pressure just equals to zero and full range
施加準確的量程零點壓力exert the accurate range zero pressure

例如for example
同時按press at the same time
結果results
施加準確的滿度壓力exert accurate full pressure
同時按press at the same time
結果results
標準壓力接近量程零點和滿度壓力Standard pressure is close to zero and full range

施加標準壓力exert standard pressure
例如for example
計算相應電流值calculate related current
例如，通過按+Z或-Z將其輸入For example, enter it by pressing the + Z or Z
結果results
施加標準壓力exert standard pressure
例如for example
計算相應電流值，例如，通過按+S或-S將其輸入Calculated corresponding current value, for example, by pressing the +S or - S to enter it

結果results
第十六頁
帶顯示標定calibration With display
兩種可能two possibilities
標準壓力恰與量程零點壓力相等Standard pressure equals to  the range zero pressure
施加準確的量程零點壓力，例如exert accurate range zero pressure, for example

同時按press at the same time
結果results
施加準確的滿度壓力,例如exert Accurate full pressure, for example
同時按press at the same time
結果results
無標準壓力no standard pressure
指定量程零點和滿度壓力Specifies the range zero and full pressure
按+z或-z直至顯示出所期望的量程零點壓力，例如press + z or -z until it shows the desired range zero pressure, for example

結果results
按+s或-S直至顯示出所期望的量程滿度壓力，例如press + z or -z until it shows the desired range full pressure, for example
結果results
第十七頁
阻尼設定damping set
開關位于位置0時，t也可用手持終端或二次表（例如FMX770）來設定If Switch is located at position 0, t can also be set by hand terminal or secondary tables (for example FMX770)

輸入input
輸出output
缺省位置1 default location 1
固定阻尼設定Fixed damping Settings
不用don’t use
第十八頁
貯存storage
貯存環境溫度storage  temperature
貯存環境濕度storage humidity
運輸transportation
產品在符合包裝的條件下運輸，在運輸過程中防止雨淋，避免受強烈振動與碰撞
Products should be transported under the condition of packaging, preventing rain and avoiding strong vibration and impact

使用期限service life
在用戶遵守使用要求、貯存、運輸規定的條件下，自用戶購進之日起，12個月內因產品質量問題，而不能正常工作時，本公司負責為用戶免費修理，更換部件或整機
If users comply with the requirements of usage, storage and transportation conditions, since the purchasing date, within 12 months due to quality problems and can't normal work, the company is responsible for free repair , replacing parts or the whole machine

產品配套Product Support
產品附件accessories of product
電纜密封套cable gland
隨機文件files with the machine
安裝使用說明installments and operating instructions
安裝使用說明書installments and operating instructions

標定證書Calibration certificate
